XBG
XGB series controllers are powerful micro PLCs available at a highly competitive price. Their reliability, ease of use, and versatile communication options make them suitable for a wide range of applications—from simple to highly complex systems. The XGB PLC series is offered in two versions, XBC and XEC (IEC programming), each available in multiple performance levels: E, U, H, and SU. With both transistor and relay output options, the series allows you to select the ideal controller based on your specific application requirements.
- The E-series (Economy) controllers are the entry-level models in the LS XGT family. They do not support additional expansion modules, but they do allow the connection of 1 option module (for 10 and 14 I/O versions) or up to 2 option modules (for 20 and 30 I/O versions).
- The SU-series (Standard Unit) controllers support up to 7 expansion modules and up to 2 option modules. They are available with 20, 30, 40, and 60 I/O terminals.
- The H-series (High Performance) controllers support up to 10 expansion modules. They are available with 32 (16 inputs, 16 outputs) and 64 (32 inputs, 32 outputs) I/O terminals.
- The U-series (Ultimate) controllers support up to 10 expansion modules, including up to two High-Speed Interface units.
- The XBM sub-series controllers are compact yet powerful PLCs that support up to 7 XGB expansion modules.
- Various expansion modules available
Catalogs
Instructions and Certificates
Code: 4723017100
XBC-DP32UA PLC-LS XBC Series Modular High Performance Ultimate-Type
LS Electric
XBC-DP32UA - Ultimate Performance AC110/240V power supply 16 DC24 input 16 Transistor source output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity...
Sign in to see the price.
Out of stock
Code: 4723017200
XBC-DP32UP PLC-LS XBC Series Modular High Performance Ultimate-Type
LS Electric
XBC-DP32UP - Ultimate Performance AC110/240V power supply 16 DC24 input 16 Transistor source output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity...
Sign in to see the price.
Out of stock
Code: 4723016000
XBC-DR28U XBC PLC LS Electric AC110/240V power supply, Ultimate type
LS Electric
XBC-DR28U - Ultimate Performance AC110/240V power supply 16 DC24 input 12 Relay output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program...
Sign in to see the price.
Out of stock
Code: 4723016200
XBC-DR28UP XBC PLC LS Electric AC110/240V power supply, Ultimate type
LS Electric
XBC-DR28UP - Ultimate Performance AC110/240V power supply 16 DC24 input 16 Relay output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program...
Sign in to see the price.
Out of stock
Code: 4723017700
XBC-DN32U/DC LS PLC XBC Series Modular Ultimate Performance 24VDC
LS Electric
XBC-DN32U/DC - Ultimate Performance 24 VDC power supply 16 DC24 input 16 Transistor (NPN) output Processing speed: 60ns/step Program capacity: 32Kstep Program memory: 384Kbyte Max. I/O points (Main + Expansion 10 stages) 352 points Dual port...
Sign in to see the price.
Out of stock
Code: 4723017800
XBC-DN32UA/DC LS PLC XBC Series Modular Ultimate Performance 24VDC
LS Electric
Processing speed: 60ns/step Program capacity: 32Kstep Program memory: 384Kbyte Analog Input 4-ch (voltage/current, 14bit) Analog output 4Ch, (voltage/current, 14bit) Max. I/O points (Main + Expansion 10 stages) 352 points Dual port...
Sign in to see the price.
Out of stock
Code: 4723017900
XBC-DN32UP/DC LS PLC XBC Series Modular Ultimate Performance 24VDC
LS Electric
XBC-DN32UP - Ultimate Performance 24 VDC power supply 16 DC24 input 16 Transistor (NPN) output 4-axis positioning Processing speed: 60ns/step Program capacity: 32Kstep Program memory 384Kbyte Max. I/O points (Main + Expansion 10 stages) 352 points...
Sign in to see the price.
Out of stock
Code: 4723018900
XBC-DP32U/DC PLC-LS XBC Series Modular High Performance Ultimate-Type 24VDC
LS Electric
XBC-DP32U/DC - Ultimate Performance 24VDC power supply 16 DC24 input 16 Transistor source output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep...
Sign in to see the price.
Out of stock
Code: 4723019100
XBC-DP32UP/DC PLC-LS XBC Series Modular High Performance Ultimate-Type 24VDC
LS Electric
24VDC power supply 16 DC24 input 16 Transistor source output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program memory 352Kbyte Max. I/O...
Sign in to see the price.
Out of stock
Code: 4723018300
XBC-DR28U/DC XBC PLC LS Electric DC24V power supply, Ultimate type
LS Electric
XBC-DR28U - Ultimate Performance 24 VDC power supply 16 DC24 input 12 Relay output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program memory...
Sign in to see the price.
In Stock (1)
Code: 4723018400
XBC-DR28UA/DC XBC PLC LS Electric DC24V power supply, Ultimate type
LS Electric
XBC-DR28UA - Ultimate Performance 24 VDC power supply 16 DC24 input 16 Relay output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program...
Sign in to see the price.
Out of stock
Code: 4723018500
XBC-DR28UP/DC XBC PLC LS Electric DC24V power supply, Ultimate type
LS Electric
XBC-DR28UP - Ultimate Performance 24 VDC power supply 16 DC24 input 16 Relay output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program...
Sign in to see the price.
Out of stock
Code: 4723030100
XBC-DR32H/DC(R) PLC-LS XBC Series Modular High Performance H-Type DC24V
LS Electric
16 DC24 input 16 Relay output Built-in Positioning Function Analogue input resolution: 14 bit Analogue output resolution: 14 bit Communication ports: 2 (RS232 and RS485) High speed inputs: Yes Input current(mA): 4 Input points: 16 Input Voltage...
Sign in to see the price.
In Stock (2)
Code: 4723030000
XBC-DN32H(R) PLC-LS XBC Series Modular High Performance H-Type
LS Electric
16 inputs, 16 transistor outputs (sink type, NPN); Max I/O points: 352 (PLC+extensions); Number of expansion modules: 10; RS232 and RS485; power supply 100-240VAC Built-in Positioning Function
Sign in to see the price.
Out of stock
Code: 4723003100
XBC-DN32H PLC-LS XBC Series Modular High Performance H-Type
LS Electric
16 inputs, 16 transistor outputs (sink type, NPN); Max I/O points: 352 (PLC+extensions); Number of expansion modules: 10; RS232 and RS485; power supply 100-240VAC.
Sign in to see the price.
Out of stock
Code: 4723016100
XBC-DR28UA XBC PLC LS Electric AC110/240V power supply, Ultimate type
LS Electric
XBC-DR28UA - Ultimate Performance AC110/240V power supply 16 DC24 input 16 Relay output 8 channel built-in analog Analog input 4Ch 14 bit resolution Analog output 4Ch 14 bit resolution Processing speed: 60ns/step Program capacity 32Kstep Program...
Sign in to see the price.
Out of stock
