SENECA T120 RTD Loop Transmiter 4-20mA 16BIT
Product code:
SEN-T120
Manufacturer:
Seneca
Loop-powered temperature transmitter for RTD (Pt100, Ni100)
Power supply: 5..30 Vdc (loop powered)
Response time: <220 ms (<620 ms with rejection 50-60 Hz)
Accuracy Class: 0,1%
Input channel: Pt100, Standard: EN 60751/A2 (ITS-90), Measuring range: -200..+650°C,
Minimum Span: 20°C, 2,3,4-wire connection, Ni100, Measuring range: -60..+650°C,
Minimum Span: 20°C, 2,3,4-wire connection
Output channel: Current (mA) 4..20, 20..4 mA (2-wire)
Thermal drift: < 100 ppm (30 ppm tipical)
Programming: EASY SETUP software (programming kit: start / end of scale measurement, connection and RTD type, rejection, measurement filter, cable resistance, fault / over-range output)
Operating temperature: -40..+85°C
Connections: Spring clamps
Dimension: Ø 43,7 x 20 mm
Standard: CE
Norms: EN 61000-6-4, EN 61000-6-2
Power supply: 5..30 Vdc (loop powered)
Response time: <220 ms (<620 ms with rejection 50-60 Hz)
Accuracy Class: 0,1%
Input channel: Pt100, Standard: EN 60751/A2 (ITS-90), Measuring range: -200..+650°C,
Minimum Span: 20°C, 2,3,4-wire connection, Ni100, Measuring range: -60..+650°C,
Minimum Span: 20°C, 2,3,4-wire connection
Output channel: Current (mA) 4..20, 20..4 mA (2-wire)
Thermal drift: < 100 ppm (30 ppm tipical)
Programming: EASY SETUP software (programming kit: start / end of scale measurement, connection and RTD type, rejection, measurement filter, cable resistance, fault / over-range output)
Operating temperature: -40..+85°C
Connections: Spring clamps
Dimension: Ø 43,7 x 20 mm
Standard: CE
Norms: EN 61000-6-4, EN 61000-6-2
