MY ALARM 2 Remote Control GSM Unit, MY2B MY2B-0-0-M-G GSM/GPRS remote alarm and data logger unit, BASIC version

Power supply: 6..15 Vdc
Absorption: 3.5 W (max)
Protection Degree: IP20
Rechargeable Battery: Li-On (1,000 mAh), autonomy from 7 to 8 h
Integrated NTC sensor: Yes
Status Signals: Power supply, GSM / GPRS, Device status
Available Functions: Preset Scenarios, Datalogger, Commands / SMS Alarms / Ringing,
Commands ring zero cost, Incremental alarmsm Record up to 250 contacts,
Fast / timed commands, Meter and timer management, App SMS and temperature management,
Up to 10 timers
Digital inputs: Nr. 4 REED Contact type inputs, PNP, Pulscap, relay freq. Max 30 Hz,
Nr. 4 counters,Nr. 10 timers
Nr. 2 inputs configurable in: Current 0..20 mA (max impedance 60 Ω); voltage 0..30 V (max impedance 100 kΩ); 16-bit resolution, accuracy 0.1% f.s.
Digital outputs:Nr. 2 (optional) SPST relay 3 A / 250 Vac
Connections: Pull-out spring terminals, 3.5 mm pitch, PUSH-PULL type SIM card connector.
SMA-f connector for GSM antenna, Micro USB port for configuration, Push-push slot for Micro SD card
Protocols: SMS
Programming: via EASY MYALARM2 7.x software
Operating Temperature: -10..+55°C (with battery not charging) 0..+45°C (charging)
Dimensions: 80 x 105 x 30 mm
Weight: 150 g
Material:ABS polycarbonate
Installation: DIN rail or wall
Certification: CE
Standards: EN60950, EN 301 511, EN 301 489-7, EN 301 489-1
